Product description
|
Mini DC/AC clamp meter |
|
|
Thanks to its pocket size and functionalities such as the Automatic detection of AC or DC currents, Inrush current measurement, or High-frequency rejection mode, DCM200MINI is the right clamp for simple but reliable current measurements on both domestic/commercial or industrial applications |
Features
- 6000 count large scale LCD display with backlit
- 10mA Resolution
- Inrush Current Measurement
- 1.5% basic DCA/ACA accuracy
- Warranty 36 months
Technical data:
|
Specifications |
Range |
Resolution |
Accuracy |
|
|
DC Current |
60.00A* |
0.01A |
±(1.5%+10D)** |
|
|
300.0A |
0.1A |
±(1.5%+5D) |
||
|
AC Current |
60.00A |
0.1A |
50 ~ 100Hz |
100 ~ 400Hz |
|
300.0A |
0.1A |
|||
|
Low-pass Filter |
60.00A |
0.01A |
50Hz / 60Hz |
|
|
300.0A |
0.1A |
|||
|
Inrush Current |
300.0A |
0.1A |
|
|
|
* There are less than 0.3A variation as measuring in different directions. |
||||
|
** Add 10D to accuracy in Auto AC & DC Sense Mode. |
||||
