Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 16A SANYOU
Product Code: SM-S-112DM
More similar products
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 16A SANYOU
Useful information
Specifications
SKU
U-2883391
Product code
SM-S-112DM
Supplier product description
Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 16A
Useful information
Supplier parameters
Product code
SM-S-112DM
AC contacts rating @R
16A / 250V AC
Body dimensions
29x12.7x15.7mm
Coil power consumption
400mW
Coil resistance
360Ω
Coil voltage max.
15.6V DC
Coil voltage min.
9V DC
Contact current max.
16A
Contact material
AgNi
Contact resistance
100mΩ
Contacts configuration
SPST-NO
Current rating
16A
Manufacturer
SANYOU
Mounting
THT
Operating temperature
-40...85°C
Rated coil voltage
12V DC
Relay series
SM
Relay variant
miniature
Switched voltage
max. 250V AC
Switching capacity
4432VA
Type of relay
electromagnetic
Supplier's product code
SM-S-112DM
Product ID
U-2883391
