DC MAXI JOLLY SV DALI - LED Driver, TCI

SKU

U-3105801

Brand

Product code

151504

Approvals

CE; EAC ; ENEC; KEMAKEUR; RCM; UKCA; UL (class 2)

Case

IP 20 (Independent Use); Square; ZHAGA AM3

Constant current

1000 mA; 1050 mA; 1100 mA; 1150 mA; 1200 mA; 350 mA; 400 mA; 450 mA; 500 mA; 550 mA; 600 mA; 650 mA; 700 mA; 750 mA; 800 mA; 850 mA; 900 mA; 950 mA

Cut-out hole diameter

84 mm; 88 mm; 90 mm

Depth

79

Dimming

1-10V - 0-10V; DALI-2 (also DALI-1); PUSH (on the Mains)

Height

22

Others

12 V AUX. output; 4/5 kV DM/CM SURGE Input Protection; ACTIVE PFC (pf>0.9); DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-War; EXTERNAL NTC INPUT; RIPPLE FREE; SELV <60V; WIDE RANGE INPUT VOLTAGE

Width

124

NomNr

151504

Brand

TCI

Supplier's product code

151504

Product ID

U-3105801
