Lithium battery LiFePO4 12.8V 20Ah M6 BT APP VOLTIUM ENERGY
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Features
- LiFePO4 technologie has up to 10 times more cycles than comparable lead acid batteries
- Double, triple or even quadruple the capacity or voltage through parallel or serial pairing
- Low self-discharge and quick and efficient charging
- Bluetooth® APP where you can monitor all relevant data of the battery
- Only 1/3 of the weight of a comparable lead acid battery.
General info
The Voltium Energy® VE-SPBT-1209 is a LiFePO4 (Lithium Iron Phosphate) battery with a built-in SMART BMS. Because we strive for high quality, we use prismatic cells which are produced according to very strict quality requirements. Because of the way our batteries are carefully manufactured they have an extreme lifespan of >3000 cycles at 1C (100%DOD) and >6000 cycles at 0,2C (100%DOD)!
The SMART BMS offers some important features like; cell balancing, temperature protection, over-discharge protection, deep-discharge protection, short circuit protection and Bluetooth® monitoring. Via the Bluetooth® function you can check all sorts of information such as; current capacity, total voltage, number of cycles, temperature, alarm history, voltage of individual cells (PRO) and much more.
One of the biggest features is the option to connect 4 batteries in series OR 4 batteries in parallel. When these batteries are connected in series, we recommend using the Voltium Energy® Battery Equalizer.
All this together makes the Voltium Energy® VE-SPBT series one of the most complete and safe batteries on the market!
The Voltium Energy® LiFePO4 Smart Battery is, among other markets, suited for the applications below:
- Sport & Recreation
- Mobility
- Transport
- Data Center
- Medical
- Fishing
Technical data
| Nominal Voltage | 12,8V (4S) |
| Rated Capacity (CC 0.2C to 10V) | 20Ah |
| Nominal Energy | 256Wh |
| Internal Resistance | ≤60mΩ |
| Terminal type | M6 |
| Cycle Life (@DOD 100% at 1C and ±25°C) | >3000 |
| Cycle Life (@DOD 100% at 0.2C and ±25°C) | > 6000 |
| Connection options | 4 in series OR 4 in parallel |
| Communication | Bluetooth® |
| Battery operation temperature range @charging | 0~45°C |
| Normal charge voltage | 14.6 ±0.1V |
| Recommended float charge voltage (for Standby use) | 13.8 ±0.1V |
| Max charge current | 20A at ±25°C |
| Recommended charge current | 0.2C |
| Charge Cut-off Voltage | 15V ±0.2V |
| Discharging temperature range | -20~60°C |
| Output Voltage Range | 10.0~14.6V |
| Max discharge current | 20A at ±25°C |
| Recommended discharge current | 0.2C |
| Pulse discharge current | 68A withstand 3s |
| Discharge Cut-off voltage | 10.0V |
| Storage Temperature | 0-25°C |
| Self-discharge rate | ≤3% per month |
| Recommended storage SOC | 50-70% SOC |
| Housing material | ABS |
| Length | 181±3mm |
| Width | 76±3mm |
| Height | 166±3mm |
| Weight | Approx. 3,0Kg |
Dowload from App Store
Download from Google Play
Useful information
Specifications
Experimental product description generated by artificial intelligence
Lithium Battery LiFePO4 12.8V 20Ah M6 BT APP VOLTIUM ENERGY
The VOLTIUM ENERGY LiFePO4 battery is a high-performance, long-lasting power solution ideal for various applications. This smart battery boasts a 12.8V voltage and 20Ah capacity, offering reliable power for extended periods. Its advanced features and user-friendly design make it a top choice for those seeking a dependable and efficient energy storage solution.
Key Features and Benefits
- Long lifespan: Enjoy up to 10 times more cycles than comparable lead-acid batteries.
- Safety: Lithium Iron Phosphate technology provides superior safety.
- Intelligent BMS: Built-in Battery Management System protects against overcharging, over-discharging, and temperature extremes.
- Versatile: Easily increase capacity or voltage through parallel or serial pairing.
- Smart Connectivity: Bluetooth connectivity allows for easy monitoring and management via the VOLTIUM ENERGY app.
- Lightweight: Weighs only 40% of a comparable lead-acid battery.
- Efficient Charging: Charges quickly and efficiently.
Applications
This versatile battery is suitable for a wide range of applications, including:
- Sport and Recreation
- Mobility
- Transport
- Data Centers
- Medical
- Solar
- Utility
- Wind
Why Choose VOLTIUM ENERGY?
VOLTIUM ENERGY is committed to providing high-quality, reliable energy storage solutions. Our LiFePO4 batteries are rigorously tested and certified to meet the highest industry standards. Choose VOLTIUM ENERGY for peace of mind and superior performance.
| Parameter | Value |
|---|---|
| Voltage | 12.8V |
| Capacity | 20Ah |
| Terminal Type | M6 |
| Connectivity | Bluetooth |
Download the VOLTIUM ENERGY app to monitor your battery's performance and status in real-time.
This description is generated using artificial intelligence (AI) and may differ from the actual product. Common AI errors may include:
- Inaccurate product features: some technical specifications, colors, sizes or other parameters may be inaccurate or omitted.
- Incorrect compatibility information: AI may provide incorrect information about the compatibility of products with other devices or systems.
- Overly Optimistic Functions: in some cases functions may be provided whose product iš doesnt really have.
- Name or Model Discrepancies: AI may misrepresent the product name or model.
If you notice inconsistencies or have questions about the description, please contact us before purchasing the product, please contact us by e-mail to you: [email protected].
