Integrated Circuit ULN2803A DIP18
The STMICROELECTRONICS ULN2803A DIP18 is an integrated circuit belonging to the Ics - Flash RAM, ROM, Controllers category. This high-performance chip is a versatile solution for various applications requiring efficient and reliable signal control.
Key Features and Functions
- Eight Darlington arrays: Provides eight independent Darlington transistor pairs, each capable of handling significant current.
- Common emitters: Simplifies circuit design and reduces component count.
- Integrated suppression diodes: Protects against voltage spikes and inductive load effects.
- High current output: Each Darlington can output up to 500mA continuously.
- High voltage output: Withstands output voltages up to 50V.
- Parallel output capability: Allows for higher current applications by connecting multiple outputs in parallel.
- Optimized input pinout: Inputs are conveniently located opposite outputs for simplified PCB layout.
- Designed for 5V TTL and CMOS logic: Ensures seamless integration with popular logic families.
Applications
The ULN2803A's robust design and high current handling capabilities make it suitable for a wide range of applications, including:
- Motor drivers
- Relay drivers
- LED drivers
- General purpose switching
Why Choose the ULN2803A?
The ULN2803A stands out due to its:
- Reliability: Built with high-quality components and rigorously tested.
- Efficiency: Minimizes power loss and maximizes performance.
- Ease of use: Simple to integrate into existing designs.
- Cost-effectiveness: Provides high performance at a competitive price.
This integrated circuit is an excellent choice for engineers and hobbyists seeking a dependable and versatile solution for high-current switching applications.
| Parameter | Value |
|---|---|
| Output Current | 500 mA |
| Output Voltage | 50 V |
| Input Voltage | 5V |
| Package | DIP18 |
