Current Clamp flexible UT281A UNI-T
Warehouse in Europe
94%+ positive feedback
30 day money back guarantee
Product description
Features
1. 2m drop proof, IP54, ETL/Intertek certified 3rd edition CE
2. Coil diameter: 0.75cm, bending length: 24.5cm for UT281A and 45.7cm for UT281C
3. Large LCD display for clear reading
4. True RMS
5. Long press INRUSH key for 2s to measure inrush current
6. Data hold, backlight, auto power off
| Basic Functions | Range | Basic Precision |
| Max current measurement (AC) | 0.00A ~ 3000A | ±(3%+5) |
| Current measurement (AC) | 0.00A ~ 30.00A | ±(3%+5) |
| Current measurement (AC) | 0.0A ~ 300.0A | ±(3%+5) |
| Current measurement (AC) | 0A ~ 3000A | ±(3%+5) |
| Inrush current measurement | 0.00A ~ 3000A | for reference |
| Frequency response | 45Hz~500Hz (sine wave) | √ |
| Jaw size | Rogowski flex coil (diameter: 8mm) | bending length: 10″ inches (24.5cm); radius: around 1.5″ inches (3.8cm) |
| True RMS measurement | 　 | √ |
| Measuring digit conversion rate | times/s | 3 |
| LCD display (TN) | interface | Single display |
| Manual range | √ | |
| Auto power off | √ | |
| Buzzer | √ | |
| Low battery indication | √ | |
| data hold | √ | |
| Manual backlight | √ | |
| Working temperature | 0°C ~ 50°C | |
| 2m drop proof | √ | |
| Protection grade | IP54 | |
| Safety certification grade | CAT IV 600V | |
| General Characteristics | ||
| Device color | red and grey | |
| Device weight | 　 | |
| Device size | 　 | 300mm × 150mm × 55mm |
| Standard individual packing | gift box, blister, English manual | |
| Standard quantity per carton | 8pcs | |
| Standard carton size | 　 | 600mm × 380mm × 270mm |
| Standard carton gross weight | 　 | 9.5kg |
Useful information
Specifications
Experimental product description generated by artificial intelligence
The UNI-T UT281A/C/E Flex Clamp Meter is a professional electrical meter designed for measuring AC current. It features a Rogowski Coil, which allows for accurate and safe measurements of current without the need to break the circuit. The UT281A/C/E series is equipped with a full range overload protection and a unique appearance, making it a reliable and durable tool for electricians and technicians.
Here are some of the key features and benefits of the UNI-T UT281A/C/E Flex Clamp Meter:
- True RMS measurement for accurate readings of AC current.
- Rogowski Coil for safe and convenient measurements without breaking the circuit.
- Full range overload protection to protect the meter from damage.
- IP54 rating for dust and water resistance.
- Impact resistance from a one-meter drop.
- Auto power off feature to conserve battery life.
- Backlight for easy viewing in low-light conditions.
- Data hold function to freeze readings for easy viewing.
The UNI-T UT281A/C/E Flex Clamp Meter is a versatile and reliable tool for a wide range of applications, including:
- Electrical troubleshooting and maintenance
- Industrial and commercial applications
- Home and DIY projects
If you are looking for a high-quality, accurate, and safe AC current clamp meter, the UNI-T UT281A/C/E Flex Clamp Meter is an excellent choice.
This description is generated using artificial intelligence (AI) and may differ from the actual product. Common AI errors may include:
- Inaccurate product features: some technical specifications, colors, sizes or other parameters may be inaccurate or omitted.
- Incorrect compatibility information: AI may provide incorrect information about the compatibility of products with other devices or systems.
- Overly Optimistic Functions: in some cases functions may be provided whose product iš doesnt really have.
- Name or Model Discrepancies: AI may misrepresent the product name or model.
If you notice inconsistencies or have questions about the description, please contact us before purchasing the product, please contact us by e-mail to you: [email protected].
